HYDRO

The Beninca HYDRO is a hydraulic operator ideally used for intensive functions that is available in different variations depending on your needs. The chrome-plated steel rod is available in 16 or 20 millimetres and has anodised profiles to ensure atmospheric agent resistance.

It also has a brass bypass valves that guarantees precise force regulation that prevents crushing during operation. HYDRO also has a cutting edge, highly viscous biodegradable oil that allows it to improve its performance even during low temperatures, making it an ideal innovative and environment-friendly technology.

Beninca HYDRO is available in the following variants:

• D18 - for gate leafs up to 1.8 metres
• HD25 - for gate leafs up to 2.5 metres
• HD30 - for gate leafs up to 3.0 metres
• HD35 - for gate leafs up to 3.5 metres
• HD40 - for gate leafs up to 4.0 metres
• HD45 - for gate leafs up to 4.5 metres
• HD50 - for gate leafs up to 5.0 metres

The Beninca HYDRO Kit comes with:

• 2 x HYDRO Post Mounted Rams
• 1 x BRAINY Control Panel
• 1 x PUPILLA Photocells
• 1 x AW 433.92Mhz Long Range Aerial
• 2 x TO.GO2WV 2 Button Transmitters

Specifications:

• Automation Type: Swing
• Kit Type: Standalone/Replacement
• Maximum Gate Weight (kg): 500
• Maximum Gate Leaf Length (M): 5
• Working Temperature (°C Min/Max): -15°C/+70°C)
• Speed (m/s): 0.013 to 0.001
• Maximum Oil Pressure: 30 Bar
• Protection Level (IP): 55
• Thrust (daN): 3200-4200
